MERIH STAINLESS, a reputable manufacturer located in Istanbul, Turkey, specializes in producing top-notch stainless steel welding consumables designed for tough industrial applications. Their AWS Class E309LMo-16 electrodes are specifically crafted for welding stainless steels and for joining dissimilar materials, including stainless and carbon steels. Renowned for their outstanding corrosion resistance and mechanical strength, these electrodes find their place in various industries such as chemical processing, power generation, and marine construction. MERIH STAINLESS is committed to delivering consistent quality and performance, equipping welders with reliable electrodes that ensure smooth arc characteristics, minimal spatter, and easy slag removal for efficient, high-quality welding outcomes.
The AWS Class E309LMo-16 electrode features a composition of about 23–25% Chromium, 12–15% Nickel, and 2–3% Molybdenum, along with a low carbon content (≤0.04%) that boosts corrosion resistance and minimizes carbide precipitation. This unique blend offers exceptional resistance to pitting and crevice corrosion, particularly in environments rich in chlorides. Mechanical properties generally include a tensile strength of ≥550 MPa, yield strength of ≥380 MPa, and elongation of ≥30%. The rutile coating ensures excellent arc stability and a pleasing weld bead appearance, making it suitable for all-position welding and particularly effective for joining dissimilar metals due to its balanced metallurgy and good dilution resistance.
| Classification | AWS A5.4, E309/309L-16 |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | AC-DCEP (Direct Current Electrode Positive) |
| Welding Position | F, V, OH, H |
| Size | 2.0 mm, 2.50 mm, 3.15 mm, 4.00 mm, 5.0 mm |
| AC/DC+ | AC or DC (+) |
| JIS Specification | BS 2926 19.9 A R |
| Other Specification | DIN 8556 E19 9 R 23 A |
| AWS E309/309L-16 Coated Electrodes Application & uses |
|
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.04 | 22.0-25.0 | 12.0-14.0 | 0.75 | 0.5-2.5 | 1.00 | 0.04 | 0.03 | 0.75 |
Contact us to get a quick quote for your requirement.
These electrodes offer excellent resistance to oxidation and corrosion. They are available in 2.5 mm, 3.2 mm, and 4.0 mm diameters, designed for light-duty applications requiring minimal coating thickness.
These electrodes are known for superior corrosion resistance and are suitable for more demanding conditions. Sizes include 3.2 mm, 4.0 mm, and 5.0 mm, with a thicker coating that enhances durability and performance under heavy-duty usage.
These electrodes provide high resistance to corrosion and oxidation, featuring shielding to protect the weld from atmospheric contamination. Available in 2.5 mm, 3.2 mm, and 4.0 mm diameters, they are ideal for stable arc welding and consistent weld quality.
Our AWS Class E309LMo-16 electrodes are carefully packed in wooden boxes with waterproof protection and lifting points for ease of transport. To ensure full client satisfaction, each order is accompanied by crucial documents such as a commercial invoice, packing list, heat treatment chart and Material Test Certificates, providing full transparency and assurance of product quality.
AWS Class E309LMo-16 electrodes are commonly used for welding stainless steels like 309, 309L, and 316 grades, as well as for connecting stainless to carbon or low alloy steels. Typical applications encompass chemical plants, pressure vessels, heat exchangers, and components in power plants that are exposed to high temperatures and corrosive environments. Their elevated molybdenum content makes them especially well-suited for harsh conditions where enhanced corrosion resistance is essential.
