AWS Class E317L-16 Electrodes Manufacturer in Istanbul, Turkey

Home > Electrodes > AWS Class E317L-16 Electrodes

SS E317L-16 Coated Electrodes Manufacturer in Bursa, SFA A5.4 E317L-16 Coated Electrode in Ankara, UNS W31713 Coated Welding Electrode in Bodrum, JIS D E317L-16 Coated Electrodes Supplier in Turkey, Stainless Steel E317L-16 Heavy Coated Electrodes in İzmir, SS E317L-16 Heavy Coated Electrodes Electrodes in Ankara, Stainless Steel Industrial E317L-16 Coated Electrodes in Istanbul, AWS E317L-16 Coated Electrodes Dealer in Antalya, AWS/ASME 5.4 E317L-16 Coated Electrodes Suppliers in İzmir

MERIH STAINLESS, a top-tier manufacturer of welding consumables located in Istanbul, Turkey, proudly presents its range of high-quality stainless steel electrodes designed for tough industrial applications. One standout product is the AWS Class E317L-16 electrode, specifically developed for welding stainless steels that demand exceptional corrosion resistance, particularly in environments exposed to chlorides and other harsh chemicals. This low-carbon electrode is user-friendly and delivers consistent performance, making it an excellent choice for welding 317 and 317L stainless steels. With rigorous quality controls in place, MERIH STAINLESS guarantees that each electrode provides reliable arc stability, minimal spatter, and easy slag removal, whether for fabrication or maintenance welding tasks.

SS UNS W31713 Coated Welding Electrode in Istanbul, AWS E317L-16 Coated Electrodes Suppliers in Ankara, AWS A5.4 E317L-16 Coated Welding Rod Price List in Bodrum, SS E317L-16 Coated Electrodes Supplier in İzmir, Stainless Steel E317L-16 Heavy Coated Electrodes Price List in Bursa, AWS Class E317L-16 Welding Electrodes Manufacturer in Antalya, AWS A5.4 E317L-16 Coated Welding Rod Supplier in Bodrum, Stainless Steel E317L-16 Coated Electrodes Supplier in İzmir, Turkey

The AWS Class E317L-16 electrodes are formulated with approximately 18–20% Chromium, 12.5–14.5% Nickel, and 3–4% Molybdenum, while keeping the carbon content to a maximum of 0.04%. The higher molybdenum content enhances resistance to pitting and crevice corrosion compared to standard 316L electrodes, making them ideal for more challenging service conditions. Typical mechanical properties include a tensile strength of ≥560 MPa, yield strength of ≥350 MPa, and elongation of ≥30%. The rutile coating ensures smooth arc performance and ease of use across all welding positions, producing weld metal with low carbon to minimize the risk of intergranular corrosion in corrosive and high-temperature settings.

AWS Class E317L-16 Electrodes Specifications

Classification	AWS A5.4, E317L-16
Form	Welding Electrode, Welding Rods
Type Of Current	AC-DCEP (Direct Current Electrode Positive)
Welding Position	F, V, OH, H
Size	2.0 mm, 2.50 mm, 3.15 mm, 4.00 mm, 5.0 mm
AC/DC+	AC or DC (+)
JIS Specification	BS 2926 19.9 A R
Other Specification	DIN 8556 E19 9 R 23 A
AWS E317L-16 Coated Electrodes Application & uses	Petroleum Chemical plant Power sector Gas Industry Hardware tools Metallurgy Machinery Construction Shipbuilding

AWS Class E317L-16 Electrodes Chemical Composition

C	Cr	Ni	Mo	Mn	Si	P	S	Cu
0.04	18.0-21.0	12.0-14.0	3.0-4.0	0.5-2.5	1.00	0.04	0.03	0.75

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Why Choose AWS Class E317L-16 Electrodes From Merih Stainless?

Largest Inventory

Customer Support

On Time Deliveries

ISO Certified

Types of AWS Class E317L-16 Electrodes

Stainless Steel AWS Class E317L-16 Light Coated Electrodes

These electrodes offer robust resistance to corrosion and are designed for welding 317L stainless steel. They typically come in sizes ranging from 2.5 mm to 4.0 mm in diameter. Their light coating ensures ease of handling and a smooth welding arc.

Stainless Steel AWS Class E317L-16 Heavy Coated Electrodes

Featuring enhanced protection against corrosion, these electrodes are ideal for welding 317L stainless steel under demanding conditions. They are available in diameters of 3.2 mm to 5.0 mm, with a thicker coating for increased durability and stability during welding.

Stainless Steel AWS Class E317L-16 Shielded Arc Electrodes

These electrodes provide superior corrosion resistance and are suited for welding stainless steel in environments requiring high protection. Available in sizes from 2.5 mm to 4.0 mm, they offer reliable performance with a shielded arc to prevent contamination and oxidation.

Merih Stainless ensures the highest quality of AWS Class E317L-16 Electrodes through rigorous testing, including hardness, chemical analysis, PMI, tensile, micro and macro structural tests, pitting resistance, and IGC testing. We guarantee superior product performance with these comprehensive checks. Additionally, we provide all necessary documentation, including commercial invoices, packaging lists, and Certificate of Origin, legalized by the Chamber of Commerce or Embassy. Our Third-Party Inspection Certificate guarantees full customer satisfaction in pricing and delivery.

Alloy E317L-16 Welding Coated Electrode Price List in Istanbul, JIS D E317L-16 Coated Electrodes Manufacturer in İzmir, Turkey, Ready Stock of Stainless Steel E317L-16 Shielded Arc Electrodes in Bursa, AWS Class E317L-16 Welding Electrodes in İzmir, SFA A5.4 E317L-16 Coated Electrode Supplier in Istanbul, UNS W31713 Coated Welding Electrode in Turkey, Stainless Steel E317L-16 Coated Electrodes Ankara, JIS D E317L-16 Coated Electrodes Supplier in Antalya

AWS Class E317L-16 Electrodes Uses

E317L-16 electrodes find extensive application in industries such as chemical processing, pulp and paper, food and beverage, and marine fabrication, where robust resistance to acids, chlorides, and high temperatures is crucial. These electrodes are perfect for welding tanks, piping systems, heat exchangers, and vessels made from 317L stainless steel, ensuring durability and reliability in demanding environments.
