MERIH STAINLESS, located in Istanbul, Turkey, stands out as a top-notch manufacturer and supplier of premium stainless steel products, with a particular focus on Stainless Steel Tees. Known for their precision engineering and durability, MERIH STAINLESS serves a variety of industrial sectors, providing products that adhere to international standards. Their Stainless Steel Tees are produced using cutting-edge manufacturing techniques, ensuring consistent dimensions, smooth finishes, and long-lasting performance. With a strong commitment to excellence and customer satisfaction, MERIH STAINLESS delivers dependable solutions for piping systems that need robust, corrosion-resistant fittings, making them a reliable partner for projects in construction, chemical, oil, gas, and other demanding industries.
These Stainless Steel Tees are primarily made from high-quality stainless steel alloys like 304 and 316, which offer outstanding corrosion resistance and strength. These alloys are a blend of iron, chromium, nickel, and sometimes molybdenum, enhancing their durability and ability to withstand extreme temperatures and chemical exposure. Mechanically, Stainless Steel Tees boast high tensile and yield strength, good hardness, and remarkable impact resistance. They maintain their structural integrity under pressure and thermal stress, making them ideal for both high-pressure and high-temperature applications. The toughness of the material ensures a long service life, low maintenance, and reliable performance in challenging industrial settings.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We ensure that every Stainless Steel Tee Fitting undergoes rigorous testing before leaving our premises, maintaining the highest quality standards at all times. Hardness Testing, Chemical Analysis (Spectro Analysis), Positive Material Identification (PMI Testing), Flattening Test, Micro and Macro Testing, Pitting Resistance Test, Flaring Test and Intergranular Corrosion (IGC) Testing are just some of the tests performed on Stainless Steel Tee Fittings before shipping.
Yes, stainless steel tees are fully recyclable. They can be melted down and reused without losing their properties, making them an environmentally friendly and sustainable material choice.
Common grades of stainless steel used in tee fittings manufacturing include 304, 304L, 316, 316L, and 321. These grades offer excellent corrosion resistance, durability, and suitability for various applications.
Yes, stainless steel tee fittings are ideal for hygienic and sanitary applications due to their corrosion resistance, smooth surfaces, and ease of cleaning, meeting strict industry standards.
Key considerations for selecting stainless steel tee fittings include material grade, corrosion resistance, pressure and temperature requirements, compatibility with media, application standards, and cost-effectiveness for long-term use.
Stainless Steel Tees play a crucial role in piping systems by connecting three pipelines, allowing fluids or gases to flow in various directions. They are vital in industries such as oil and gas, chemical processing, water treatment, and power generation. These fittings enable system branching, distribution, and flow regulation while ensuring structural integrity and corrosion resistance. Additionally, Stainless Steel Tees are utilized in HVAC systems, food and beverage processing, and pharmaceutical applications, where hygiene and resistance to contamination are paramount.
