Home > Sheet and Plates > Stainless Steel 253MA Sheet and Plates
MERIH STAINLESS, based in Istanbul, Turkey, is a reliable manufacturer and supplier of top-notch stainless steel products. Their Stainless Steel 253MA Sheets and Plates are specifically designed to withstand extreme high temperatures and corrosive environments, boasting remarkable strength, oxidation resistance, and durability. Crafted to meet international standards, these sheets and plates offer precise dimensions, a smooth surface finish, and dependable mechanical performance. Perfect for industries like power generation, petrochemical, chemical processing, and marine applications, MERIH STAINLESS 253MA sheets and plates promise long-lasting, maintenance-free performance. They’re also great for fabrication, forming, and welding, providing sturdy solutions in demanding industrial settings.
Stainless Steel 253MA Sheets and Plates are made from a blend of iron, chromium, and nickel, with added molybdenum and nitrogen, which gives them outstanding high-temperature strength along with excellent resistance to oxidation and corrosion. On the mechanical side, they showcase high tensile and yield strength, impressive creep resistance, hardness, and good ductility, making them easy to fabricate and weld without losing structural integrity. This alloy maintains its shape even under extreme thermal stress and harsh chemical conditions. These features ensure that 253MA sheets and plates perform reliably in critical high-temperature, corrosive, and industrial environments where durability and safety are essential.
Stainless Steel Sheets and Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| Cr | Ni | Si | C | Mn | P | S | N | Ce | Fe | |
|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 20.00 | 10.00 | 1.40 | 0.05 | – | – | – | 0.14 | 0.03 | Balance |
| MAX | 22.00 | 12.00 | 2.00 | 0.10 | 0.80 | 0.04 | 0.03 | 0.20 | 0.08 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Reduction Area,% |
|---|---|---|---|---|
| 253 MA | 87,000 | 45,000 | 40 | 50 |
Contact us to get a quick quote for your requirement.
Hot-rolled stainless steel 253MA sheets are manufactured by a process known as hot rolling at elevated temperatures, ensuring robust and tough materials. Thickness usually ranges between 3mm to 100mm. Excellent resistance to corrosion and oxidation in a high temperature is one of its excellent characteristics.
These stainless steel 253MA cold rolled plates are made at room temperature, giving these plates a smooth finish with very precise dimensions. Thickness is available from 0.3mm up to 3mm and offers high resistance against corrosion. They are ideal for applications wherein tight tolerances and high quality of surface finish can be achieved.
Stainless Steel 253MA Chequered Sheets provide a raised diamond pattern for improved grip and aesthetics. Available in gauges between 3mm and 12mm, these sheets have corrosion resistance properties. The product is widely used in floorings, walkways, and decorative applications.
Stainless Steel 253MA perforated plates offer evenly spread holes, used for ventilation, filtration, and decorative purposes. They offer these plates in various hole sizes, available from 0.5mm to 5mm thickness. They have excellent corrosion resistant and good for applications where they need to allow airflow and drainage.
Stainless Steel 253MA Shim Sheets are thin and precise sheets applied for adjustments and alignment in machinery and structures. They are offered in a variety of thickness from 0.1mm up to 3mm. Their excellent corrosion resistance makes them critical for tight tolerance applications in numerous industries.
Stainless Steel 253MA Polished Plates are buffed to a reflective, mirror-like finish. The plates are available in thicknesses from 0.3mm to 50mm. They are used in architectural, decorative, and high-visibility applications due to their superior corrosion resistance.
Merih Stainless prioritizes delivering a seamless customer experience backed up by thorough documentation of the premium-quality Stainless Steel 253MA Sheets and Plates. Essential documents include the commercial invoice, packing list, fumigation certificate, heat treatment chart, quality assurance plan, and NABL-approved lab test report. These documents create authenticity and superior quality of our products that earn the trust of our esteemed clients. Moreover, we offer Stainless Steel 253MA sheets and plates with various test certificates including MTC as per EN 10204/3.1b, PMI Test Certificate, 100% radiography test report and Third-Party Inspection Certificate. These test certificates indicate our customer-centric approach while achieving excellence in every product.
Stainless Steel 253MA Sheets and Plates find their place in various industries that demand exceptional heat and corrosion resistance. They’re perfect for boiler components, heat exchangers, furnace parts, chemical processing equipment, petrochemical plants, power generation systems, and marine applications. These sheets and plates are also suitable for piping, structural frameworks, and industrial machinery that face extreme temperatures and aggressive corrosive conditions.
